Description

Full service repair manual

Language English

Pages: 392

High quality .pdf, searchable and printable version, no watermarks, instant download.

250 XC-W EU (F7303427)
250 XC-W US (F7375427)
300 EXC EU (F7403727)
300 EXC BR (F7440627)
300 EXC SIX DAYS EU (F7403227)
300 EXC SIX DAYS BR (F7440227)
300 EXC HARDENDURO EU (F7403327)
300 XC-W US (F7475327)
300 XC-W HARDENDURO US (F7475627)

What’s Inside

Engine
The two-stroke engine chapter covers teardown and reassembly, including replacement of the connecting rod and crank pin. It also shows how to inspect the exhaust control and service the reed valve housing.
Take off the connecting rod and bearing. (p. 224)

Front Suspension
The fork chapter gives separate stripdown and rebuild procedures for Hardenduro and the other models. It shows how to separate the fork tubes, remove the sliding bushings and seals, and reassemble the cartridges.
Remove the piston rod. (p. 27)

Rear Suspension
The rear shock procedure covers dismantling the damper, taking the pistons and shim stacks off the piston rod, and rebuilding the rod and damper in sequence.
Remove rebound shim stack (p. 94)

Maintenance and Electrical
The manual includes wiring diagrams, a service schedule, and technical specifications. It gives reference resistance values for the stator and ignition coil, and voltage values for checking the crankshaft position sensor and throttle position sensor (TPS).
