Description

Full service repair manual

Language English

Pages: 304

High quality .pdf, searchable and printable version, no watermarks, instant download.

85 SX 19/16 (F6001927)
85 SX 17/14 (F6001827)

What’s Inside

Engine
The engine chapter covers piston and cylinder inspection, crankshaft runout checks, and examining the transmission after disassembly. The carburetor chapter covers cleaning, reassembly, and adjustment.
Check the piston bearing surface for damage. (p. 186)

Front Suspension
The fork procedure shows how to separate the fork tubes and strip the cartridges. During reassembly it covers refitting the cartridge piston and seal ring retainer before putting the fork legs back together.
Mount the seal ring retainer. (p. 40)

Rear Suspension
The rear shock rebuild covers taking the damper apart, stripping the piston rod and seal ring retainer, and reassembling the piston and shim stacks.
Mount the piston. (p. 80)

Maintenance and Electrical
The wiring diagram shows the ignition circuit. The manual gives reference readings for the ignition coil, stator charging coil, and crankshaft position sensor, with resistance and voltage checks as applicable. It also covers the maintenance schedule, brakes, and hydraulic clutch.
